Teflon Cartridge core for titanium and stainless steel tube shell heat exchanger

Main technical parameters:

A. The heat exchanger is made of 9,6,5,3 tube bundles welded into the core of heat exchanger. The shell is made of PP, titanium, stainless steel and carbon steel, lined with Tetrafluoro or PO. The heat transfer surface of the teflon heat exchanger tube bundle is sealed in the shell.

B. Product temperature range:-150 ~ 260 °C; working pressure: Steam ≤0.5 MPA; refrigerant ≤1.5 MPA.

C. Using capillary heating, thin surface wall, surface non-stick, small diameter, high pressure, good soft resistance.

D. Product Quality Inspection: In closed circuit system, saturated steam 0.3 MPA stable pressure 1 hour; cold pressure single pipe 1.4 MPA stable 8 hours; welding strength: > 50 n/root.

 MATERIAL CHARACTERISTICS:

1.Because of the non-viscosity and self-cleaning property of fluoroplastics, almost all the mediums can not stick to its surface and there will be no dirt when it is used. Therefore, the heat exchanger made of fluoroplastics has a certain self-cleaning function, at the same time, the fluorine plastic Tube Bundle is light in weight, will have the slight vibration when using.

2. The surface of the fluoroplastic heat exchanger tube is smooth, the friction coefficient is small, and the fluoroplastic heat exchanger tube is elastic compared with the metal heat exchanger tube, because of the light weight of fluoroplastic heat exchanger, the weight of fluoroplastic heat exchanger is lighter than that of traditional metal heat exchanger under the same working condition.

3. Has good thermal stability, flexibility, crack resistance and transparency, is a continuous processing, able to adapt to extremely high processing environment.

4. The product is soft and can be bent into any shape. But curvature radius ≥150 mm, and has a very high fire resistance, excellent electrical insulation, high density of non-polar materials, with excellent dielectric properties, the process does not produce leakage and amphoteric electrode.

5. Excellent anti-aging performance: Molecular non-photosensitive gene, ozone and ultraviolet rays can not work with it, immersed in strong corrosive medium, and exposed to bad atmosphere for a long time; It is highly chemically stable. The structural formula is a linear polymer with complete symmetry and no branched chains. The molecule has no polarity and its chemical properties are quite stable, in strong acid, strong alkali, oxidant, oxide, Aqua regia and other solutions in long-term contact safe and sound, can withstand 0-100% boiling hydrofluoric acid concentration so that the service life of the equipment up to 8-10 years.

Article 1: (product warranty rules)

 the corrosion-resistant pump series of the Bao electroplating within one year due to its own quality defects (not including the following factors: improper use, man-made damage, natural disasters, etc.) problems, to give free repair pump. If the last day of the validity period is a statutory holiday, the day following the holiday shall be the last day of the validity period.

Article 2: (the rules of free maintenance for the corrosion-resistant pump series liquid heaters)

the corrosion-resistant pump package replacement of the plated pump package shall meet the following 5 working conditions to carry out after-sales maintenance:

1, after-sales warranty period

2, the product corrosion-resistant pump can not work abnormal

3, non-human reasons corrosion-resistant pump contact damage cracking

4, corrosion-resistant pump use pressure abnormal phenomenon

5, non-production environment change products corrosion or damage phenomenon.

Article 3: after-sales Maintenance Channels (reference service network)

1, dial the The Adjuster line: 4006-090-950

2, sales outlets contact maintenance

3, agents contact maintenance,

pOSTAGE: We use Guangdong Province Express, Guangdong Province outside the logistics, in our company to order the PO series products, need to negotiate with the PO Company to pay freight, freight inquiry logistics companies. Online shopping can not avoid the need for logistics and transportation. Please sign for the package, everything must check the integrity of the package, as well as the number and integrity of goods inside the package. If the delivery person does not allow you to sign for it, you can sign for it and then disassemble it on the logistics side. If you have any problems, return it in person
